BLB19 Brushless DC Motor Parking Barrier

Description

Product Overview



Representing the “New Generation” of parking barrier in the parking industry, the BLB19 is the first choice for the demanding commercial market. With a 4 year motor warranty for commercial use, the BLB19 is one of the most elegantly designed commercial barriers available in today’s market. It includes a heavy duty, high-efficiency gear motor with no belts, or chains needed to drive the gearbox.This product is ideal for  gated communities, parking lots, and very high traffic applications, The barrier arm is easily released manually by utilizing the Key Release mechanism and can be automatically sequenced with Platinum Access System’s slide, or swing gate operators.


Features and Benefits:

 1.  Continuous Duty.

   2.  90 degree opening in 3-6 seconds.

 3.  Select 120VAC/220VAC Power Input source.

 4.  Custom made high efficiency gear motor for very high traffic application.

 5.  Pending for ETL List. UL 325 and UL 991 Compliant.

 6.  GOC-6000 Control board with Input/Output LEDs.

 7.  Electronic reversing sensor built into control board.

 8.  Adjustable delay timer from 0-60 seconds.

 9.  Speed adjustment for both Open and Close.

 10.  Open angle adjustment.

 11.  Manual Release for Emergency Exit.

 12.  Open Left, or Right.

 13. Auto open which opens the gate automatically when the primary 120VAC/220VAC Power source failed. Gate(s) keep open till the primary 120VAC/220VAC power source has been restored.

 14.  Solid State Motor Drivers – Provides a quietness and longer product life cycle.

 15.  High Capacity DC BackUp – Using two 12V, 7Ah batteries that can  opens and closes the gate over 100 cycles on DC backup depending on the model and gate size.

 16.  Automatic sequencing when using with special made Platinum slide, or swing operator.

 17. Soft Start and Soft Stop – Minimizes wear and tear on the gate system for an increased gate system life usage.

 18.  Built-In very reliable Surge Protection.

 19.  Motor breaker.

 20. 110VAC output outlet.

 21.  Come with Dual Output Loop Detector Rack – Type “B” relays on the loop detector can be used for additional features.

 22.  Commercial parts warranty:  2 years.

 23.  Battery (as the main power source) warranty: 6 months.

24.  Super quiet operation.

25.  Adjustable precision limit switches.

26.  Built-In efficient switch power supply that can output a stable voltage to the main board and the actuator arm to keep the gate travel at the same speed even when the input power voltage is fluctuating.

27.  Built-In mechanical Positive Stop to prevent the Arm over travel.

28.  Optional connecting flash LED Light to the Aluminum Arm.

29.  Charcoal Gray- Powder Coated Metal chassis.

30.  Working temperature is between -4°F to +158°F.

Additional information

Gate Capacity

Gate Length
